Side-Power SE100 Bow Thruster System 12v

Top quality bow thruster system

Built for outstanding performance, you can rely on your
Side-Power SE100 Bow Thruster System to help you
gain full control of your vehicle. As marinas get more crowded and
slips become tighter, docking your boat safely is more challenging
than ever before. Thrusters give you total control of your vehicle
and allow you to manoeuvre in and out of tight spots with ease and
actual control of your boat.

This heavy-duty Side-Power SE100 Bow Thruster
System offers the help you need to be in full control when
docking and departing, regardless of wind, conditions and currents.
It features a high-powered electric motor that’s made to achieve
maximum performance in real-life conditions while still keeping
weight, size and power consumption to a minimum.

The gear house is made of seawater-resistant bronze for optimum
protection from the elements. Its slim and hydrodynamic design
keeps water resistance and turbulence to a minimum. Trusted by
boaters around the world, you can’t go wrong with a system as
reliable as a Side-Power system!

Twin Propeller System
The twin propeller system can give more thrust than a single
propeller system in the same tunnel diameter. Due to the compact
design and high performance, the twin models have become the
thrusters of choice among boat builders around the world.

Galvanic Separation
The gearhouse of Side-Power DC Electric thrusters are now fully
galvanically isolated from the electric motor and motor bracket.
This ensures that even if there is an accidental short circuit or a
current leak for other reasons, the immersed parts are not effected
as they could be with direct electric contact.

Side-Power SE100 Bow Thruster System 12v
Features:

• Intelligent Power Control
• Twin Propeller System
• -Sealed gear leg with long-life mechanical seal
• Galvanic Separation
• Q prop

Side-Power SE100 Bow Thruster System 12v
Specifications:

• Thrust at 10.5V/21V: 100kg (220lb)
• Thrust at 12V/24V: 116kg (256lb)
• Typical boat size: 35-55ft (12 – 17m)
• Tunnel I.D.: 185mm (7.3in)
• Propulsion system: twin
• Power at 10.5V/21V: 6.3kw (8.4Hp)
• For DC system (V): 12/24
• Weight: 31kg (68lb)
• Min. Batt. Cap (CCA** 12/24V): 750/400

What’s in the box:

• 1 x Side-Power SE100 12v Thruster
• 1 x Joy Stick
• 1 x Fuse and Holder
• 1 x 1.2m Tunnel and 9 Wiring Loom

Side-Power Bow Thrusters Product Brochure
